| X, Y, Z Axis Travel |
60 x 30 x 24 in (1524 x 762 x 610 mm)
|
| T-slot size |
7 x .71 in (7 x 18 mm)
|
| Max. Weight on Table |
3,000 lbs (1,360 kg)
|
| Table size |
66 x 30 in (1,676 x 762 mm)
|
| Max. spindle speed |
8000 rpm
|
| Spindle Power (peak - 1 min) |
29.7 hp (22.2 kW)
|
| Spindle Torque (peak - 1 min) |
260 ft. lbs @ 600 rpm (353 Nm @ 600 rpm)
|
| Tool Type |
CAT 50
|
| Number of Tools |
30
|
| Max. tool diameter |
4.9 in (125 mm)
|
| Max. tool length |
11.8 in / 300 mm
|
| Max. tool weight |
33 lbs / 15 kg
|
| Rapid Traverse X,Y,Z Axis |
1260, 1260, 944 in/min (32, 32, 24 m/min)
|
| Max. Programmable Feedrate |
944 in/min (24 m/min)
|
| Max. Operating Floor Space |
222.6 x 185.5 in (5654 x 4712 mm)
|
| Machine Height |
130 in (3303 mm)
|
| Machine weight |
22267 lbs (10100 kg)
|
