AWEA HTP-5041 Production Bridge Mill

The highly rigid HTP series is equipped with a high torque spindle for outstanding heavy cutting performance. It can easily increase the chip removal rate, reduce cycle time and complete tough material machining easily.

Strong spindle unit structure
The U-shaped saddle design with four linear guideways and ten sliding blocks supporting the Z-axis gives the spindle head firm support. Even with the Z-axis fully extended, the machine can still maintain excellent machining accuracy.

Best linear guideway arrangement
High quality 4 linear guideways supporting the X-axis and 3 guideways supporting the Y-axis allow the HTP series to easily surpass its competition in structural rigidity, table load and accuracy.

Flexible multi-face machining capability
An automatic head changer and a two positions ATC system are optional upgrades for improved multi-face machining.
A new generation of in-house made attachment heads is available now.

Exceptional capability of chip removal and cooling
Standard two coil type chip augers and a caterpillar type chip conveyor efficiently remove chips. The 1000L coolant tank effectively reduces cutting fluid heating, thus ensuring better machining accuracy.

Additional Information

X-axis Travel

Y-axis Travel

Z-axis Travel

Table size ( X x Y )

Table load capacity

Spindle taper

Spindle motor ( cont. / 30 min. )

Spindle speed

X-axis rapid feed rate

Y/Z axes rapid feed rate

Cutting feed rate

Tool magazine capacity

Max. tool length

Max. tool weight

Repeatability ( JIS B 6338 )

Power requirement

Coolant tank capacity

Machine weight


Dist. between columns

Repeatability ( VDI 3441 )

Hydraulic tank capacity
