| X, Y, Z Axis Travel |
42 x 24 x 24 in (1067 x 610 x 610 mm)
|
| T-slot size |
5 x .71 in (5 x 18 x 100 mm)
|
| Max. Weight on Table |
3,000 lb (1,750 Kg)
|
| Table size |
50 x 24 in (1,270 x 610 mm)
|
| Max. spindle speed |
12000 rpm
|
| Spindle Power (peak - 1 min) |
24 hp (18 kW)
|
| Spindle Torque (peak - 1 min) |
175 ft. lbs @ 720 rpm (237 Nm @ 720 rpm)
|
| Tool Type |
CAT 40 / Big Plus® (CAT or BT 40)
|
| Number of Tools |
30 or 40
|
| Max. tool diameter |
3.1 in (79 mm)
|
| Max. tool length |
11.8 in / 300 mm
|
| Max. tool weight |
15.4 lb (7 kg)
|
| Rapid Traverse X,Y,Z Axis |
1496, 1496, 1260 in/min (38, 38, 32 m/min)
|
| Max. Programmable Feedrate |
1260 in/min (32 m/min)
|
| Max. Operating Floor Space |
180 x 149.9 in (4572 x 3680 mm)
|
| Machine Height |
115 in (2,920 mm)
|
| Machine weight |
14,330 lbs (6,500 kg)
|
